Publication 1734-UM016A-EN-P - October 2010
34 1734/1738 I/O Module Assembly Information
TagName
TabName[High Byte]
Layout for Array data:
TagName[0]
TagName[1]
TagName[2]
: :
TabName[N]
Module Specific Details
Two-channel Discrete Input Modules
All two-channel discrete input modules use the same configuration and input
assemblies. Use the tables shown below for the following modules:
• 1734-IB2 or 1738-IB2
• 1734-IV2 or 1738-IV2
• 1734-IA2 or 1738-IA2
• 1734-IM2 or 1738-IM2
Configuration Assembly Instance 103
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Input 0 Off to On Filter Low Byte
1 Input 0 Off to On Filter High Byte
2 Input 0 On to Off Filter Low Byte
3 Input 0 On to Off Filter High Byte
4 Input 1 Off to On Filter Low Byte
5 Input 1 Off to On Filter High Byte
6 Input 1 On to Off Filter Low Byte
7 Input 1 On to Off Filter High Byte
Produced Input Data Assembly 2
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Ch 1 Ch 0
