Publication 1734-UM016A-EN-P - October 2010
32 1734/1738 I/O Module Assembly Information
Analog and Specialty I/O Modules
1734-OB2EP
1738-OB2EP
2 point 24V DC 2A Protected output 123 8 1 1
1734-IA2
1738-IA2
2 point 120V AC input 103 8 1 0
1734-IA4 4 point 120V AC input 103 16 1 0
1734-IM2 2 point 220V AC input 103 8 1 0
1734-IM4 4 point 220V AC input 103 16 1 0
1734-OA2
1738-OA2
2 point 120V/220V AC output 103 4 0 1
1734-OA4 4-channel 120V/220V AC output 103 4 0 1
1738-IB16 16 point 24V DC sink input 103 6 2,3 0
1738-OB16 16 point 24V DC source input 123 2 1 2
1734-8CFG
1738-8CFG
8 point 24V DC configurable sink
input/source output
103 8 1 1
(1)
While these modules (OB2, OB4, and OB8) have no meaningful data, they return a byte of 0 to be compatible with the "E" modules. In this manner they can be interchanged.
Also these modules expect the same 8-byte configuration assembly even though only the first 4 bytes are meaningful.
POINT I/O and ArmorPOINT I/O Discrete I/O modules
Cat. No Description Configuration
Assembly
Instance
Configuration
Size
Produced Size Consumed Size
POINT and ArmorPOINT Analog and Specialty I/O modules
Cat. No Description Configuration
Assembly
Instance
Configuration
Size
Produced Size Consumed Size
1734-VHSC5 1 point 5V, 2 out very high speed counter 108 54 6 2,2,4
1734-VHSC24
1738-VHSC24
1 point 24V, 2 out very high speed counter 108 54 6 2,2,4
1734-IJ
1738-IJ
1 point 5V counter 123 18 6 1
1734-IK 1 point 24V counter 123 18 6 1
1734-IE2C
1738-IE2C
2 point analog current input 123 38 6 0
1734-IE4C
1738-IE4C
4 point analog current input 123 74 12 0
1734-IE8C 8 point analog current input 123 146 24 0
1734-OE2C
1738-OE2C
2 point analog current output 123 36 2 4
