31 Publication 1734-UM016A-EN-P - October 2010
Chapter
5
1734/1738 I/O Module Assembly Information
Module Assembly
Information
Discrete Modules
POINT I/O and ArmorPOINT I/O Discrete I/O modules
Cat. No Description Configuration
Assembly
Instance
Configuration
Size
Produced Size Consumed Size
1734-IB2
1738-IB2
2 point DC sink input 103 8 1 0
1734-IB4
1738-IB4
4 point DC sink input 103 16 1 0
1734-IB4D
1738-IB4D
2 point DC sink input with diagnostics 103 18 2,1 0
1734-IB8
1738-IB8
8 point DC sink input 103 32 1 0
1734-IV2 2 point DC source input 103 8 1 0
1734-IV4
1738-IV4
4 point DC source input 103 16 1 0
1734-IV8
1738-IV8
8 point DC source input 103 32 1 0
1734-OB2E
1738-OB2E
2 point DC source output 123 8 1 1
1734-OB4E
1738-OB4E
4 point DC source output 123 8 1 1
1734-OB2 2 point DC source output 123 8
1
(1)
1
1734-OB4 4 point DC source output 123 8 1 1
1734-OB8 8 point DC source output 123 8 1 1
1734-OB8E
1738-OB8E
8 point DC source output 123 8 1 1
1734-OW2 2 point relay output 103 4 0 1
1734-OW4
1738-OW4
4 point relay output 103 4 0 1
1734-OV2E 2 point 24V DC sink output 123 8 1 1
1734-OV4E
1738-OV4E
4 point 24V DC sink output 123 8 1 1
1734-OV8E 8 point 24V DC sink output 123 8 1 1
1734-OX2 2 point Form C Relay output 103 4 0 1
