Publication 1734-UM016A-EN-P - October 2010
Assembly Structure 29
Produce 14 Slot 2 Channel 0 - Low Byte
Produce 15 Slot 2 Channel 0 - High Byte
Produce 16 Slot 2 Channel 1 - Low Byte
Produce 17 Slot 2 Channel 1 - High Byte
Produce 18 Slot 2 Channel 0 - Status
Produce 19 Slot 2 Channel 1 - Status
Produce 20 Slot 3 Channel 0 - Low Byte
Produce 21 Slot 3 Channel 0 - High Byte
Produce 22 Slot 3 Channel 1 - Low Byte
Produce 23 Slot 3 Channel 1 - High Byte
Produce 24 Slot 3 Channel 0 - Status
Produce 25 Slot 3 Channel 1 - Status
Produce 26 Slot 4 ARM - Reserved Byte
Produce 27 Slot 4 ARM - Reserved Byte
Produce 28 Slot 4 ARM - Reserved Byte
Produce 29 Slot 4 ARM - Reserved Byte
Produce 30 Slot 4 ARM - Reserved Byte
Produce 31 Slot 4 ARM - Reserved Byte
Produce 32 Slot 5 ARM - Reserved Byte
Produce 33 Slot 5 ARM - Reserved Byte
Produce 34 Slot 5 ARM - Reserved Byte
Produce 35 Slot 5 ARM - Reserved Byte
Produce 36 Slot 5 ARM - Reserved Byte
Produce 37 Slot 5 ARM - Reserved Byte
Produce 38 Reserved Slot 6 Bit 3 Slot 6 Bit 2 Slot 6 Bit 1 Slot 6 Bit 0
Produce 39 Pad
Produce 40 Pad
Produce 41 Pad
Produce 42 Pad
Produce 43 Pad
Produce 44 Slot 7 Bit 3 Slot 7 Bit 2 Slot 7 Bit 1 Slot 7 Bit 0
Produce 45 Pad
Produce 46 Pad
Produce 47 Pad
Produce 48 Pad
Produce 49 Pad
Produce 50 Slot 8 Bit 3 Slot 8 Bit 2 Slot 8 Bit 1 Slot 8 Bit 0
Produce 51 Pad
Produced Assembly, Fixed Size per Slot Alignment
Byte Bit 7 Bit 6 Bit5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
