Assembly Structure 27
Produce 17 Slot 8 Bit 15 Slot 8 Bit 14 Slot 8 Bit 13 Slot 8 Bit 12 Slot 8 Bit 11 Slot 8 Bit 10 Slot 8 Bit 9 Slot 8 Bit 8
Produce 18 Pad
Produce 19 Pad
Produce 20 Slot 9 Channel 0 - Low Byte
Produce 21 Slot 9 Channel 0 - High Byte
Produce 22 Slot 9 Channel 1 - Low Byte
Produce 23 Slot 9 Channel 1 - High Byte
Produce 24 Slot 9 Channel 0 - Status
Produce 25 Slot 9 Channel 1 - Status
Produce 26 Pad
Produce 27 Pad
Produce 28 Slot 10 ASCII Data 1
Produce 29 Slot 10 ASCII Data 2
Produce 30 Slot 10 ASCII Data 3
Produce 31 Slot 10 ASCII Data 4
Produce 32 Slot 10 ASCII Data 5
Produce 33 Slot 10 ASCII Data 6
Produce 34 Slot 10 ASCII Data 7
Produce 35 Slot 10 ASCII Data 8
Produce 36 Slot 10 ASCII Data End of String Delimiter
Produce 37 Slot 11 ARM - Reserved Byte
Produce 38 Reserved Slot 13 Bit 3 Slot 13 Bit 2 Slot 13 Bit 1 Slot 13 Bit 0
Produced Assembly, Double Word Aligned
Byte Bit 7 Bit 6 Bit5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Consumed Assembly, Double Word Aligned
Byte Bit 7 Bit 6 Bit5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Consume 0 Reserved Run/Idle
Consume 1 Reserved
Consume 2 Reserved
Consume 3 Reserved
Consume 4 Reserved Slot 4 Bit 1 Slot 4 Bit 0
Consume 5 Reserved Slot 5 Bit 3 Slot 5 Bit 2 Slot 5 Bit 1 Slot 5 Bit 0
Consume 6 Slot 6 Bit 7 Slot 6 Bit 6 Slot 6 Bit 5 Slot 6 Bit 4 Slot 6 Bit 3 Slot 6 Bit 2 Slot 6 Bit 1 Slot 6 Bit 0
Consume 7 Pad
Consume 8 Slot 10 ASCII Data 1
Consume 9 Slot 10 ASCII Data 2
Consume 10 Slot 10 ASCII Data 3
