Publication 1734-UM016A-EN-P - October 2010
26 Assembly Structure
Consumed Assembly, Word Aligned
Byte Bit 7 Bit 6 Bit5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Consume 0 Reserved Run/Idle
Consume 1 Reserved
Consume 2 Reserved
Consume 3 Reserved
Consume 4 Reserved Slot 4 Bit 1 Slot 4 Bit 0
Consume 5 Reserved Slot 5 Bit 3 Slot 5 Bit 2 Slot 5 Bit 1 Slot 5 Bit 0
Consume 6 Slot 6 Bit 7 Slot 6 Bit 6 Slot 6 Bit 5 Slot 6 Bit 4 Slot 6 Bit 3 Slot 6 Bit 2 Slot 6 Bit 1 Slot 6 Bit 0
Consume 7 Pad
Consume 8 Slot 10 ASCII Data 1
Consume 9 Slot 10 ASCII Data 2
Consume 10 Slot 10 ASCII Data 3
Consume 11 Slot 10 ASCII Data 4
Consume 12 Slot 10 ASCII Data 5
Consume 13 Slot 10 ASCII Data End of String Delimiter
Consume 14 Reserved Slot 12 Bit 3 Slot 12 Bit 2 Slot 12 Bit 1 Slot 12 Bit 0
Produced Assembly, Double Word Aligned
Byte Bit 7 Bit 6 Bit5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Produce 0 Slot 7 status Slot 6 status Slot 5 status Slot 4 status Slot 3 status Slot 2 status Slot1 status Slot 0 status
Produce 1 Slot 15 status Slot 14 status Slot 13 status Slot 12 status Slot 11 status Slot 10 status Slot 9 status Slot 8 status
Produce 2 Slot 23 status Slot 22 status Slot 21 status Slot 20 status Slot 19 status Slot 18 status Slot 17 status Slot 16 status
Produce 3 Slot 31 status Slot 30 status Slot 29 status Slot 28 status Slot 27 status Slot 26 status Slot 25 status Slot 24 status
Produce 4 Slot 39 status Slot 38 status Slot 37 status Slot 36 status Slot 35 status Slot 34 status Slot 33 status Slot 32 status
Produce 5 Slot 47 status Slot 46 status Slot 45 status Slot 44 status Slot 43 status Slot 42 status Slot 41 status Slot 40 status
Produce 6 Slot 55 status Slot 54 status Slot 53 status Slot 52 status Slot 51 status Slot 50 status Slot 49 status Slot 48 status
Produce 7 Slot 63 status Slot 62 status Slot 61 status Slot 60 status Slot 59 status Slot 58 status Slot 57 status Slot 56 status
Produce 8 Reserved Slot 1 Bit 3 Slot 1 Bit 2 Slot 1 Bit 1 Slot 1 Bit 0
Produce 9 Slot 2 Bit 7 Slot 2 Bit 6 Slot 2 Bit 5 Slot 2 Bit 4 Slot 2 Bit 3 Slot 2 Bit 2 Slot 2 Bit 1 Slot 2 Bit 0
Produce 10 Reserved Slot 3 Bit 1 Slot 3 Bit 0
Produce 11 Reserved Slot 4 Bit 1 Slot 4 Bit 0
Produce 12 Reserved Slot 5 Bit 3 Slot 5 Bit 2 Slot 5 Bit 1 Slot 5 Bit 0
Produce 13 Slot 6 Bit 7 Slot 6 Bit 6 Slot 6 Bit 6 Slot 6 Bit 4 Slot 6 Bit 3 Slot 6 Bit 2 Slot 6 Bit 1 Slot 6 Bit 0
Produce 14 Slot 7 Bit 7 Slot 7 Bit 6 Slot 7 Bit 5 Slot 7 Bit 4 Slot 7 Bit 3 Slot 7 Bit 2 Slot 7 Bit 1 Slot 7 Bit 0
Produce 15 Pad
Produce 16 Slot 8 Bit 7 Slot 8 Bit 6 Slot 8 Bit 5 Slot 8 Bit 4 Slot 8 Bit 3 Slot 8 Bit 2 Slot 8 Bit 1 Slot 8 Bit 0
