16 Using an Assembly Connection
6. The Configuration Setting tab displays the configuration options for the
connection. Here, you can specify the Chassis Size and Data Alignment.
The terms T2O and O2T are abbreviations for Target to Originator and
Originator to Target.
Use an Assembly
Connection with
RSLogix5000
The Assembly connection can be used with RSLogix5000 and the Generic
EtherNet/IP profile. When this connection is used in RSLogix5000, there are
no intelligent Tags created for the adapter. All Input, Output, and
Configuration data are in unstructured Tag arrays.
TIP
Remember when specifying the Chassis Size to include 1 for the
adapter.
See Data Alignment for alignment choices.
