User Manual

ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 15
Publication
1738-IN023B-EN-E - February 2010
ArmorPoint 24V DC Output Modules, Series A - 1738-OB16E19M23,
1738-OB16EM12, 1738-OB16E25DS
Attribute Value
Number of outputs 1 group of 16, nonisolated sourcing outputs
On-state voltage drop 0.2V DC maximum
On-state voltage 10V DC minimum
24.V DC nominal
28.8V DC maximum
On-state current
per channel
1.0 mA minimum
0.5 A maximum, electronically protected
Off-state voltage 28.8V DC maximum
External DC supply voltage 10...28.8V DC range
24V DC nominal
Off-state current leakage 0.5 mA
Output current rating 4.0 A per module maximum
0.5 A per channel maximum
Output surge current 1 A maximum, electronically protected
Output delay time
(1)
OFF to ON /
ON to OFF
0.1 ms
Output point density 16
Pilot duty rating 1.3 A Inrush
(1)
OFF to ON or ON to OFF delay is time from a valid output on or off signal to output energization or
de-energization.
