Specifications
ArmorPoint 24V DC Input Module, Series A - 1738-IB16DM12
Attribute Value
Inputs per module 1 group of 16, nonisolated
On-state voltage 10V DC minimum
24V DC nominal
28.8V DC maximum
On-state current 2 mA minimum
4 mA @ 24V DC nominal
5 mA maximum
Off-state voltage 5V DC
Off-state current 1.5 mA
Current, sensor
source, per input
50 mA maximum
Current, sensor
source, per module
800 mA maximum
Field power supply
voltage range
10...28.8V DC
Input delay time
(1)
OFF to ON /
ON to OFF
(1)
Input OFF to ON or ON to OFF delay is time from a valid input signal to recognition by the module.
0.5 ms hardware + (0…63 ms selectable)
Input point density 16
