User Manual

ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 13
Publication
1738-IN023B-EN-E - February 2010
Network status Off Device is not online:
- Device has not completed dup_MAC-id test.
- Device not powered – check module status
indicator.
Green Device is online and has connections in the
established state.
Flashing green Device is online but has no connections in the
established state.
Flashing red One or more I/O connections in timed-out state
Red Critical link failure – failed communication
device. Device detected error that prevents it
from communicating on the network.
Flashing red/green Communication faulted device – the device has
tdetected a network access error and is in
communication faulted state.
Device has received and accepted an Identity
Communication Faulted Request – long protocol
message.
I/O status Off Output is not energized or input is not valid.
Yellow Output is energized or input is valid.
1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS, 1738-IB16DM12
Indicator Status
Status Description
