Default Data Map for Output Modules
1738-OB16E19M23, 1738-OB16E25DS, and 1738-OB16EM12
1738-IB16DM12
76543210
Produces 0
(scanner Rx)
Not used Fault
LED
state
Fault
12-15
Fault
8-11
Fault
4-7
Fault
0-3
Consumes 0
(scanner Tx)
O7 06 05 04 03 02 01 0O
Consumes 1 O15 O14 O13 O12 O11 O10 O9 O8
Where: O = Output
0 = off, 1 = on
76543210
Produces 0
(scanner Rx)
I7 I6 I5 I4 I3 I2 I1 I0
Produces 1 I15 I14 I13 I12 I11 I10 I9 I8
Produces 2 Not used Fault
LED
state
SSV
Fault
12-15
SSV
Fault
8-11
SSV
Fault
4-7
SSV
Fault
0-3
Where: I = Input
0 = off, 1 = on
