12 POINT I/O 2 Current and 2 Voltage Input Analog Modules
Publication
1734-IN027A-EN-E - May 2005
Channel Current
Input
Chassis
Ground
Common Supply
0024 6
1135 7
12/24V dc is provided by the internal field power bus.
In 0 In 1
Chas
Gnd
Chas
Gnd
C
C
V
V
Current
Input
Device
2-wire
42018in
3
5
7
01
2
4
6
Current
Input
Device
4-wire
ac or
dc
1734-IE2C POINT I/O 2 Current Input Analog Module
In = Input channel
Chas Gnd = Chassis Ground
C = Common
V = 12/24V dc supply
