Installation Instructions Owner's manual

20
Publication
1734-IN582B-EN-P - February 2005
ESD Immunity IEC 61000-4-2: 6kV contact discharges 8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to
2000MHz
10V/m with 200Hz 50% pulse 100%AM from 900MHz
EFT/B Immunity IEC 61000-4-4:
+
4kV at 5.0kHz on power ports
+
2kV at 5.0kHz on communications ports
Surge Transient Immunity IEC 61000-4-5:
+
1kV line-line(DM) and +2kV line-earth(CM) on power ports
+2
kV line-earth(CM) on communications ports
Conducted RF Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to
80MHz
Emissions CISPR 11 Group 1, Class A
Enclosure Type Rating None (open-style)
Power Conductors
Wire Size
ControlNet Conductors
Wiring Category
1,2
14 AWG (2.5mm
2
) - 22 AWG (0.25mm
2
) solid or stranded
copper wire rated at 75
o
C or higher 3/64 inch (1.2mm)
insulation maximum
See Publication CNET-IN002A
1 - on power ports
2 - on communications ports
Terminal Base Screw Torque 7 pound-inches (0.6Nm)
Mass 9.0 oz/255 grams
Publications - User Manual 1734-UM008
