Publication 1732E-UM002A-EN-P - March 2010
86 1732E EtherNet/IP ArmorBlock Supporting Sequence of Events Data Tables
All data listed in this assembly is in Little Endian format, LSB first, in
increasing byte order to MSByte last.
Consumed Assembly Instance 139
CIP Sync
Consumed
Byte
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0-3 Event Ack (32 bit)
4NewData
Ack 7
NewData
Ack 6
NewData
Ack 5
NewData
Ack 4
NewData
Ack 3
NewData
Ack 2
NewData
Ack 1
NewData
Ack 0
5NewData
Ack 15
NewData
Ack 14
NewData
Ack 13
NewData
Ack 12
NewData
Ack 11
NewData
Ack 10
NewData
Ack 9
NewData
Ack 8
6 Point To Retrieve
7 Reserved Retrieve
By Point
Reset
Events
Where: EventAck
• Is a 0 or 1 to indicate acknowledging an OnOff or OffOn event respectively, or a 2 to acknowledge both.
NewDataAck
• When transitioned from 0 to 1, acknowledges the corresponding input’s timestamp and clears its NewData and
EventOV bits in produced instance 118. EventAck determines which OffOn and/or OnOff timestamps are
acknowledged by the NewDataAck bits.
PointToRetrieve: Not used
RetrieveByPoint: Not used
Reset Events: When transitioned from 0 to 1, erases all recorded time stamped events.
