83 Publication 1732E-UM002A-EN-P - March 2010
Appendix
C
1732E EtherNet/IP ArmorBlock Supporting
Sequence of Events Data Tables
Communicate with Your
Module
Read this section for information about how to communicate with your
module.
I/O messages are sent to (consumed) and received from (produced) the
ArmorBlock I/O modules. These messages are mapped into the processor’s or
scanner’s memory. The following table lists the assembly instances and
connection points for the 1732E EtherNet/IP ArmorBlock Supporting
Sequence of Events.
Produced Assembly Instance 118
16 Point Input / Status / CIP Sync
Produced
Byte
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved (Must be 0)
1 Reserved (Must be 0)
2 Reserved (Must be 0)
3 Reserved (Must be 0)
4 IN 7IN 6IN 5IN 4IN 3IN 2IN 1IN 0
5 IN 15 IN 14 IN 13 IN 12 IN 11 IN 10 IN 9 IN 8
6 INOW 7 INOW 6 INOW 5 INOW 4 INOW 3 INOW 2 INOW 1 INOW 0
7 INSC 7 INSC 6 INSC 5 INSC 4 INSC 3 INSC 2 INSC 1 INSC 0
8 NewData 7 NewData 6 NewData 5 NewData 4 NewData 3 NewData 2 NewData 1 NewData 0
9 NewData 15 NewData 14 NewData 13 NewData 12 NewData 11 NewData 10 NewData 9 NewData 8
10 EventOV 7 EventOV 6 EventOV 5 EventOV 4 EventOV 3 EventOV 2 EventOV 1 EventOV 0
11 EventOV 15 EventOV 14 EventOV 13 EventOV 12 EventOV 11 EventOV 10 EventOV 9 EventOV 8
12-15 Event Number (32 bit)
16-23 Local clock Offset (64 bit)
24-31 Offset Time Stamp (64 bit)
32-39 Grandmaster Clock ID (64 bit) 8 byte SINT array
40-47 IN 0 Off-On Time Stamp (64 bit)
48-55 IN 0 On-Off Time Stamp (64 bit)
56-63 IN 1 Off-On Time Stamp (64 bit)
64-71 IN 1 On-Off Time Stamp (64 bit)
72-79 IN 2 Off-On Time Stamp (64 bit)
80-87 IN 2 On-Off Time Stamp (64 bit)
