Publication 1732E-UM002A-EN-P - March 2010
Module Tags 81
I.OffsetTimeStamp DINT[2] Modulewide The time when the PTP message was received to cause the Local Clock Offset
to update.
This value is initially zero. The first timestamp occurs when the module
synchronizes with the Grandmaster clock.
I.GrandMasterClockID DINT[2] Modulewide The I.D. number of the Grandmaster clock that the module is synchronized to.
I.Timestamp[16].OffOn[2] DINT[2] Per point Timestamp value with an input’s OFF to ON transition. This tag is a 16 x 2 32-bit
array.
This value is cleared after the data has been acknowledged via the O.EventAck
and O.NewData tags. For more information on clearing timestamp data, see
see page 64
.
I.Timestamp[16].OnOff[2] DINT[2] Per point Timestamp value with an input’s ON to OFF transition. This tag is a 16 x 2 32-bit
array.
This value is cleared after the data has been acknowledged via the O.EventAck
and O.NewData tags. For more information on clearing timestamp data, see
page 64
.
I.SyncedToMaster BOOL Modulewide Indicates if the module is synchronized with a master clock.
1 = Synchronized
0 = Not synchronized
(1)
With the Per point tags, there is one bit per input. For example, bit 0 represents input 0, bit 7 represents input 7 and so on.
Input Tags
Tag Name Type Set on Per
Point or
Modulewide
basis
Description
