Using the Module 59
Click the Configuration tab.
• Select the individual boxes for
each input point to enable
Timestamp Capture for that
point.
• Unselect the individual boxes
for each input point to disable
Timestamp Capture for that
point.
You can also use these boxes to enable
or disable all points simultaneously.
