Configure RSLogix 5000 and
the 1756-EN2T
Communication Module for
CIP Sync
If you are using RSLogix 5000 version 17, follow these steps to configure the
1756-EN2T communication module to be the PTP (CIP Sync) master clock.
1. In your web browser, go to the Rockwell Automation Sample Code
Library at
http://samplecode.rockwellautomation.com/idc/groups/public/docu
ments/webassets/sc_home_page.hcst.
The Search Our Sample Code Library page appears.
2. In the Filename/ID field enter MMS_048132.
3. Click Search.
The 1732E EtherNet/IP ArmorBlock Supporting Sequence of Events
module synchronizes to the grandmaster clock as a slave module as
described in the document.
If you are using RSLogix 5000 version 18 or greater, refer to publication
IA-AT003
for instructions on configuring the 1756-EN2T communication
module and the ContolLogix processor so that the processor can function as
the PTP (CIP Sync) master clock.
Chapter Summary and
What’s Next
In this chapter, you read about configuring your module in RSLogix 5000. The
next chapter describes the module Features.
