Getting Started
4
Drive Features
Terminal cover
Fault relay terminals
RS422 serial interface
Power terminal block
Debris
cover
Front case
To wire the power terminals
Control terminal block
Screw
Protective earth ground
connection
and fault relay, loosen the
screw and open the front
case.
Note that for ratings AA01-
AA03 the screw is located
under the control terminal
block cover.
Control terminal block cover
RS422 serial interface
Heat sink
Enclosure
Screw
Fixed keypad
