Parameters & Programming
32
1
U = 60 Hz default settings, K = 50 Hz default settings. Settable using
P
b85 – [Factory Default Select]
Parameter
Number
Parameter Name / Description Min./Max
Range
Units Factory
Defaults
Initialization / Adjustment Function U
1
K
1
b88 [FRS Select]
Selects operation of the drive after a digital input
(C01 – C05) setting 11{FRS} input is removed.
Settings: 00=0 Hz start
01=Synchronization of motor speed
after waiting period programmed via
Pb03 – [Restart Time].
00/01 Numeric Value 00 00
b89 [Reserved]
Reserved for Future Use, DO NOT CHANGE
01/07 Numeric Value 01 01
b92 [Reserved]
Reserved for Future Use, DO NOT CHANGE
00/01 00
