Bulletin 1606 Switched Mode Power Supplies
10. EMC
This redundancy module is suitable for applications in industrial environment as well as in residential, commercial and
light industry environment without any restrictions (e.g. cable length). The CE Mark indicates conformance with EMC
directive 2004/108/EC and the low-voltage directive (LVD) 2006/95/EC.
A detailed EMC report is available upon request.
EMC Immunity
According generic standards: EN 61000-6-1 and EN 61000-6-2
Electrostatic discharge EN 61000-4-2 Contact discharge
Air discharge
8kV
15kV
Criterion A
Criterion A
Electromagnetic RF eld EN 61000-4-3 80MHz-2.7GHz 10V/m Criterion A
Fast transients (Burst) EN 61000-4-4 Input lines
Output lines
Alarm contacts
2kV
2kV
2kV
Criterion A
Criterion A
Criterion A
Surge voltage on
input lines
EN 61000-4-5 + -
+/-
Chassis ground
200V
1kV
Criterion A
Criterion A
Surge voltage on
output lines
EN 61000-4-5 + -
+/-
Chassis ground
200V
1kV
Criterion A
Criterion A
Surge voltage on
alarm contacts
EN 61000-4-5 Alarm contact Chassis ground 1kV Criterion A
Conducted disturbance EN 61000-4-6 0.15-80MHz 10V Criterion A
Power-frequency magnetic
eld *)
EN 61000-4-8 50Hz 30A/m Criterion A
Criteria:
A: Redundancy module shows normal operation behavior within the dened limits.
Notes:
*) A test is not applicable according to EN 61000-6-2, since the device does not contain components susceptible to magnetic elds, e.g. hall
elements, electrodynamic microphones, etc.
EMC Emission
According generic standards: EN 61000-6-3 and EN 61000-6-4
Conducted emission IEC/CISPR 16-1-2, IEC/CISPR 16-2-1 Class B, input lines *)
IEC/CISPR 16-1-2, IEC/CISPR 16-2-1 Class B, output lines *)
Radiated emission EN 55011, EN 55022 Class B
This device complies with FCC Part 15 rules.
Operation is subjected to following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
*) Provided that power sources connected on the inputs fulll the class B requirements as well.
