Bulletin 1606 Switched Mode Power Supplies
6. Reliability
The redundancy module does not include electrolytic capacitors. Therefore, the lifetime expectancy and MTBF
value are extremely high.
Input / output
current conditions
Input: 2x10A
Output: 20A
Input: 2x5A
Output: 10A
Lifetime expectancy
*) min. 25 years 25 years at 24V and 40°C
min. 25 years 25 years at 24V and 25°C
MTBF
**) SN 29500, IEC 61709 9 100 000h 10 900 000h at 24V 40°C
15 700 000h 18 800 000h at 24V 25°C
MTBF
**) MIL HDBK 217F 9 200 000h 11 100 000h at 24Vand 40°C (Ground Benign GB40)
12 600 000h 15 100 000h at 24Vand 25°C (Ground Benign GB25)
3 380 000h 4 060 000h at 24Vand 40°C (Ground Fixed GF40)
4 630 000h 5 570 000h at 24Vand 25°C (Ground Fixed GF25)
*) The Lifetime expectancy shown in the table indicates the minimum operating hours (service life).
**) MTBF stands for Mean Time Between Failure, which is calculated according to statistical device failures, and indicates reliability of a
device. It is the statistical representation of the likelihood of a unit to fail and does not necessarily represent the life of a product.
7. Terminals and Wiring
Input and output terminals Alarm-signal terminals
Type Screw terminals
IP20 Finger safe construction.
Suitable for eld installation.
Screw terminals, pluggable
IP20 Finger safe construction.
Suitable for eld installation.
Solid wire 0.5-6mm
2
0.2-1.5mm
2
Stranded wire 0.5-4mm
2
0.2-1.5mm
2
American Wire Gauge 20-10 AWG 22-14 AWG
Wire stripping length 7mm / 0.28inch 6mm / 0.25inch
Screwdriver 3.5mm slotted or Pozidrive No 2 3mm slotted
Recommended tightening torque 0.8Nm / 7lb.in 0.4Nm / 3.5lb.in
Instructions:
a) The external circuitry of all terminals (including signalling contacts) must meet the safety requirements stipulated by
IEC/EN/UL 60950-1: SELV.
b) Use appropriate copper cables that are designed for minimum operating temperatures of:
60°C for ambient up to 45°C and
75°C for ambient up to 60°C minimum.
c) Follow national installation codes and installation regulations!
d) Ensure that all strands of a stranded wire enter the terminal connection!
e) Up to two stranded wires with the same cross section are permitted in one connection point.
f) Screws of unused terminal compartments should be securely tightened.
g) Ferrules are allowed, but not required.
h) Do not connect or disconnect the wires from the terminals below -25°C (-13°F).
