Bulletin 1606 Switched Mode Power Supplies
Catalog Number: 1606-XLERED
Index
egaP egaP
1. Intended Use .......................................................3
2. Installation Requirements...................................3
3. Input and Output Characteristics .......................4
4. Power Losses........................................................5
5. Alarm Contacts ....................................................5
6. Reliability .............................................................6
7. Terminals and Wiring..........................................6
8. Functional Diagram.............................................7
9. Front Side and User Elements.............................7
10. EMC......................................................................8
11. Environment ........................................................9
12. Protection Features ...........................................10
13. Safety Features ..................................................10
14. Dielectric Strength ............................................10
15. Certications .....................................................11
16.
Environmental Compliance ............................. 11
17. Physical Dimensions and Weight ..................... 12
18. Accessory ........................................................ 13
19. Application Notes............................................. 14
19.1. Recommendations for Redundancy .........14
19.2. Inductive and Capacitive Loads ................14
19.3. Example: 1+1 Redundancy up to 10A ......14
19.4. Example: N+1 Redundancy up to 30A .....15
19.5. Example: Battery Back-up ........................15
19.6. Example: Redundancy for Controls .........16
19.7. Example: Decoupling of Branches ...........17
19.8. Use in a Tightly Sealed Enclosure ............17
19.9. Mounting Orientations ............................18
•PE and symbol—PE is the abbreviation for Protective Earth and has the same meaning as the symbol .
•Earth, Ground—This document uses the term “earth” which is the same as the U.S. term “ground”.
• T.b.d.—To be defined, value or description will follow later.
• AC 230V—A figure displayed with the AC or DC before the value represents a nominal voltage with standard tolerances (usually ±15%)
included. E.g.: DC 12V describes a 12V battery disregarding whether it is full (13.7V) or flat (10V)
• 230Vac—A figure with the unit (Vac) at the end is a momentary figure without any additional tolerances included.
• 50Hz vs. 60Hz—As long as not otherwise stated, AC100V and AC230V parameters are valid at 50Hz and AC120V parameters are valid at 60Hz
mains frequency.
•may—A key word indicating flexibility of choice with no implied preference.
•shall—A key word indicating a mandatory requirement.
•should—A key word indicating flexibility of choice with a strongly preferred implementation.
Terminology and Abbreviations
