Operation
The output switch of all devices is normally open. When the monitored current
exceeds the trip value of 1.5 Amps, the switch closes.
Specifications
All other trademarks are the property of their respective holders, and are hereby acknowledged.
Current Switch Specifications
Specification Value
Output Type Mosfet
Type AC/DC
Switch V Max 30Vac/40Vdc
I Max 500 mA
Von @ 24Vdc @ 150 mA <0.1 V
Leakage Current <25 µA
Auto Range Yes
Input I Min 1.5A
Input I Max 200A
