Installation Instructions Current Switch Catalog Number(s) 1414-CC20PTWZB Publication 1414-IN002A-EN-P - October 2005
Current Switch Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://www.literature.rockwellautomation.com) describes some important differences between solid state equipment and hard-wired electromechanical devices.
Current Switch 3 Install the Current Switch Disconnect and lock-out all power sources during installation as severe injury or death can result from electrical shock due to contact with high voltage conductors. Ensure all installations are in compliance with applicable electrical codes and that the installation is completed by qualified installers familiar with the standards and proper safety procedures for high-voltage installation.
Operation The output switch of all devices is normally open. When the monitored current exceeds the trip value of 1.5 Amps, the switch closes. Specifications Current Switch Specifications Specification Value Output Type Mosfet Type AC/DC Switch V Max 30Vac/40Vdc I Max 500 mA Von @ 24Vdc @ 150 mA <0.1 V Leakage Current <25 µA Auto Range Yes Input I Min 1.5A Input I Max 200A All other trademarks are the property of their respective holders, and are hereby acknowledged.
