User Manual

Motor Protection Circuit Breakers 140M-C..., 140M-D...
Application Instruction for Protection of EEx e Motors Please read this first
Time-current characteristics
Catalog Number Current Range [A] Drawing
140M-C2E-A16
0.10...0.16 21.022.100
140M-C2E-A25 0.16...0.25 21.022.101
140M-C2E-A40
0.25...0.4 21.022.102
140M-C2E-A63 0.4...0.63 21.022.103
140M-C2E-B10
0.63...1.0 21.022.104
140M-C2E-B16 1.0...1.6 21.022.105
140M-C2E-B25
1.6...2.5 21.022.106
140M-C2E-B40 2.5...4.0 21.022.107
140M-C2E-B63
4.0...6.3 21.022.108
140M-C2E-C10 6.3...10 21.022.109
140M-C2E-C16
10...16 21.022.110
140M-C2E-C20 14.5...20 21.022.111
140M-C2E-C25
18...25 21.022.112
140M-D8E-B25
1.6...2.5 21.022.106
140M-D8E-B40 2.5...4.0 21.022.107
140M-D8E-B63
4.0...6.3 21.022.108
140M-D8E-C10 6.3...10 21.022.109
140M-D8E-C16
10...16 21.022.110
140M-D8E-C20 14.5...20 21.022.111
140M-D8E-C25
18...25 21.022.112
Tag the desired Catalog Number
