1397 Enhanced Field Supply Card
7
1397-5.24 March, 2005
1.5-30 HP/230V Drives
3-60
HP/460V Drives
with Carrier Door Open
100-150
HP/230V Drives
200-300
HP/460V Drives
— Bottom —
40-75
HP/230V Drives
75-150
HP/460V Drives
with Auxiliary Panel Cover Removed
181 182
183
GRD
A1
45
P4
P4
P4
S4
S4
S4
P4
P4
P4
S4
S4
S4
P4
P4
P4
S4
S4
S4
P4
P4
P4
S4
S4
S4
81 82
83
P4
P4
P4
P4
P4
P4
P4
400-600 HP/460V Drives — Bottom
P4
P4
P4
S4
S4
S4
Installation, Cont’d
❏ 8 For 1.5-30HP230V & 3-60HP/460V drives, plug the Enhanced
Field Supply connector P4 into Power Interface Board connector
P4.
For 40-150HP/230V drives
& 75-600HP/460V drives, plug the
Enhanced Field Supply connector P4 into Power Interface Board
connector S4.
