Reference Adapter Board User guide
Table Of Contents
Chapter 2
Hardware Description
2-5
Table 2.A
Digital
Reference Adapter Board Connections
Connector
J2
Type
20 pin Discrete Wire
Purpose
Connection for Analog I/O Hardware
and Digital Reference Encoder Input
Device via TB3 terminals 23 - 42
J1
60 pin Ribbon
Connection to Main Control Board
J3
20 pin Discrete Wire
Connection for Digital I/O Hardware
devices via TB3 terminals 43 - 62
Table 2.B
Digital
Reference Adapter Board Jumpers
Position
Factory Set, Do Not Alter
Jumper
J4
J5 Factory Set, Do Not Alter
J6
Factory Set in Position 12 (used for 5V or 12V driver circuits)
J7
Factory Set in Position 12 (used for 5V or 12V driver circuits)
