Related Documentation
The following documents contain additional information concerning
related Allen-Bradley products. To obtain a copy, contact your local
Allen-Bradley office or distributor. For the National Electrical Code,
you may need to contact the publisher.
‘
Terms and Abbreviations The following terms and abbreviations are specific to this product.
For a complete listing of Allen-Bradley terminology, refer to the
Allen-Bradley Industrial Automation Glossary.
For: Read this document: Document number:
In-depth information on grounding and wiring Allen-Bradley
programmable controllers
Allen-Bradley Programmable Controller
Grounding and Wiring Guidelines
1770-4.1
A description on how to install a PLC-5

system
PLC-5 Family Programmable Controllers
Hardware Installation Manual
1785-6.6.1
A description of important differences between solid-state
programmable controller products and hard-wired
electromechanical devices
Application Considerations for Solid-State
Controls
SGI-1.1
An article on wire sizes and types for grounding electrical
equipment
National Electrical Code
Published by the National Fire
Protection Association of
Boston, MA.
A complete listing of current Allen-Bradley documentation,
including ordering instructions. Also indicates whether the
documents are available on CD-ROM or in multi-languages.
Allen-Bradley Publication Index SD499
A glossary of industrial automation terms and abbreviations
Allen-Bradley Industrial Automation
Glossary
AG-7.1
This term: Has the following definition:
bandwidth
Bandwidth is the frequency range from ω = 0 to the point at which the magnitude response of the speed
regulator is 0.707 of (or 3db below) its zero frequency (steady-state) value. The bandwidth indicates the rise
time or speed of response of the speed regulator. ω = 2πf, where f is Hz or cycles per second.
destination parameter (read
and write parameters)
Destination parameters accept data from other parameters. The drive uses this data to perform the desired
functions. An example of a destination parameter is Speed Ref 1 (parameter 29), which can accept a speed
reference from a device such as a PLC. Throughout this manual, the following symbol indicates a destination
parameter:
Destination parameters may also be called sink parameters.
display units
Display units are the units that are displayed on the Human Interface Module (HIM). Display units are units such
as Hz, volts, and rpm, and are converted to and from drive units by the HIM.
drive units
Drive units are the actual values of the parameters as stored within the drive parameter table. The drive units
are converted to display units that are shown on the Human Interface Module (HIM). Drive units may also be
called internal units.
EE or E
2
See non-volatile memory.
frame size
A single-letter designator used to identify the various drive sizes. Frame sizes are frequently referred to instead
of the kW or horsepower rating they represent. Refer to Chapter 1, Overview, to determine the frame size for
your drive.
