5-4 Using the L Option
Setting Up the L Option Board To use the L Option board, you need to:
1. Choose the L Option input mode that is best for your application.
2. Record the selected mode number:
Selected Mode Number: ______________________________
3. Wire the L Option board according to the input mode you
selected.
4. Enter the input mode number during the digital set up portion of
the start up procedure. The input mode is then used for the value
of L Option Mode (parameter 116). This step is covered in
Chapter 6, Starting Up Your System.
Choosing the L Option Mode
To choose the L Option mode that is best for your application, you
need to:
1. Determine the type of start/stop/direction control you want.
2. Determine the remaining control functions that you want.
3. Use Table 5.A, Figure 5.1 and Figure 5.2 to determine the input
mode number.
