Mounting and Wiring Information Specific to Frames B, C, D, E, F, G, and H 4-13
Dimensions for Frame E
All Dimensions in Milimeters and (Inches).
All Weights in Kilograms and (Pounds).
C Max.
D
A
Y
CC
E
B
Z
BB
AA
Mounting Holes (4) – See Detail
37.9
(1.49
)
Mounting Hole Detail
See
Bottom View Dimensions
for Details
Dia. 10.2 (0.40)
17.0 (0.67)
Dia. 19.1 (0.75)
Frame
Reference
A B C Max. D E Y Z AA BB CC
Shipping
Weight
E — Enclosed
511.0
(20.12)
1498.6
(59.00)
424.4
(16.71)
477.5
(18.80)
1447.8
(57.00)
16.8
(0.66)
40.1
(1.61)
195.0
(7.68)
901.4
(35.49)
151.9
(5.98)
186 kg
(410 lbs)
E — Open
511.0
(20.12)
1498.6
(59.00)
372.6
(14.67)
477.5
(18.80)
1447.8
(57.00)
16.8
(0.66)
40.1
(1.61)
138.4
(5.45)
680.0
(26.77)
126.3
(4.97)
163 kg
(360 lbs)
