Mounting and Wiring Information Specific to Frames B, C, D, E, F, G, and H 4-11
Input Fusing Requirements The following are the input fusing requirements for frames B, C, D,
E, F, G, and H.
Maximum Recommended AC Input Line Fuse Ratings (fuses are user supplied)
European Installations
North American
Installations
Drive Catalog
Number
kW (HP)
Rating
200 – 240V
Rating
380 – 480V
Rating
500 – 600V
Rating
The recommended fuse is
Class gG, general industrial
applications and motor circuit
protection.
BS88 (British Standard) Parts 1
& 2*, EN60269-1, Parts 1 & 2,
type gG or equivalent should be
used for these drives. Fuses
that meet BS88 Parts 1 & 2 are
acceptable for Frames A – F.
* Typical designations include,
but may not be limited to the
following:
Parts 1 & 2: AC, AD, BC, BD,
CD, DD, ED, EFS, EF, FF, FG,
GF, GG, GH.
UL requirements specify
that UL Class CC, T, or J
1
fuses must be used for all
drives in this section*.
* Typical designations
include:
Type CC: KTK, FNQ-R
Type J: JKS, LPJ
Type T: JJS, JJN
UL requirements specify
that UL Class CC, T, or J
1
fuses must be used for all
drives in this section*.
* Typical designations
include:
Type CC: KTK, FNQ-R
Type J: JKS, LPJ
Type T: JJS, JJN
1336E-_ _ 007 5.5 (7.5) 40A 20A 15A
1336E-_ _ 010 7.5 (10) 50A 30A 20A
1336E-_ _ 015 11 (15) 70A 35A 25A
1336E-_ _ 020 15 (20) 100A 45A 35A
1336E-_ _ 025 18.5 (25) 100A 60A 40A
1336E-_ _ 030 22 (30) 125A 70A 50A
1336E-_ _ X040 30 (40) 150A 80A 60A
1336E-_ _ 040 30 (40) 150A 80A 60A
1336E-_ _ 050 37 (50) 200A 100A 80A
1336E-_ _ X060 45 (60) — 100A —
1336E-_ _ 060 45 (60) 250A 125A 90A
1336E-_ _ 075 56 (75) 300A 150A 110A
1336E-_ _ 100 75 (100) 400A 200A 150A
1336E-_ _ 125 93 (125) 450A 250A 175A
1336E-_ _ X150 112 (150) — 250A —
1336E-_ _ 150 112 (150) — 300A 225A
1336E-_ _ 200 149 (200) — 400A 350A
1336E-_ _ 250 187 (250) — 450A 400A
1336E-_ _ X300 224 (300) ——400A
The recommended fuse is
Class gG, general industrial
applications and motor circuit
protection.
BS88 (British Standard) Part 4,
EN60269-1, Part 4*, type gG
semiconductor fuses or
equivalent should be used for
these drives. G Frame drives
require semiconductor fuses
and should be fused with Part 4
fuses.
* Typical designations include,
but may not be limited to the
following:
Part 4: CT, ET, FE, EET, FEE,
RFEE, FM, FMM.
Bussmann FWP/Gould
Shawmut A-70Q or QS
semiconductor type fuses
must be used for all drives
in this section.
1336E-_ _ 300 224 (300) — 500A 400A
1336E-_ _ P300
2
224 (300) —
500A
2
—
1336E-_ _ 350 224 (300) — 600A 450A
1336E-_ _ P350
2
261 (350) —
600A
2
—
2
1336E-_ _ 400 298 (400) — 600A 500A
1336E-_ _ P400
2
298 (400) —
600A
2
—
2
1336E-_ _ 450 336 (450) — 800A 600A
1336E-_ _ P450
2
336 (450) —
700A
2
—
2
1336E-_ _ 500 373 (500) — 800A 800A
1336E-_ _ 600 448 (600) — 900A 800A
1336E-_ _ 650 485 (650) ——800A
1336E-_ _ 700C
2
522 (700) —
600A
3
700A
3
1336E-_ _ 800C
2
597 (800) —
700A
3
700A
3
1 Both fast acting and slow blow are acceptable.
2 Fuses are supplied with F and H Frame drives.
3 Two fuses in parallel are required.
