User Manual V 1-4.XX User guide

Mounting and Wiring Information Specific to Frames B, C, D, E, F, G, and H 4-5
Figure 4.4
Drive Connections for Frames E, F, and G
R
(L1)
S
(L2)
T
(L3)
R
S
T
200-240V, 56-75 kW (75-100 HP) Terminal Designations
380-480V, 112-187 kW (150-250 HP) Terminal Designations
500-600V, 112-224 kW (150-300 HP) Terminal Designations
380-480V, 224-448 kW (300-600 HP) Terminal Designations
500-600V, 187-448 kW (250-600 HP) Terminal Designations
TE
BUS INPUT OUTPUT
–DC+DC PE PE R-L1 S-L2 T-L3 U-M1 V-M2 W-M3
Required
Input Fusing
To Motor
To Motor
AC Input Line
Required
Input Fusing
AC Input Line
typical terminal layout
(located at top of drive)
W
(M3)
U
(M1)
V
(M2)
E Frame
G Frame
Required Branch
Circuit Disconnect
Required Branch
Circuit Disconnect
To Motor
typical terminal
380-480V, 187-336 kW (250-450 HP) Terminal Designations
To Motor
T-L3
R-L1
S-L2
W-M3
U-M1PE
V-M2
F Frame
Input Fusing
(Supplied)
AC Input Line
Required Branch
Circuit Disconnect
DC –
Brake
DC +
Brake
Connect the -DC Brake
to the -Bus to the drive.
Brake terminals are located on the
DC choke behind the "U" terminal.
Access the DC Choke from
the right side of the chassis.
Connect the +DC Brake
to the +Bus to the drive.
Refer to the Troubleshooting
Guide for information on
accessing the DC Bus Inductor.
1
1
1
1 User supplied.
