4-4 Mounting and Wiring Information Specific to Frames B, C, D, E, F, G, and H
Figure 4.3
Drive Connections for Frames C and D
PE PE TE
DC +
Brake
Required
Input Fusing
DC –
Brake
R
(L1)
S
(L2)
T
(L3)
W
(T3)
U
(T1)
V
(T2)
To Motor
AC Input Line
200-240V, 30-45 kW (40-60 HP) Terminal Designations
380-480V, 45-112 kW (60-150 HP) Terminal Designations
500-600V, 56-112 kW (75-150 HP) Terminal Designations
D
Frame
Required Branch
Circuit Disconnect
To Motor
PE
GRD
PE
GRD
DC
+
Dynamic Brake
Required
Input Fusing
DC
–
R
(L1)
S
(L2)
T
(L3)
W
(T3)
U
(T1)
V
(T2)
To Motor
AC Input Line
200-240V, 15-22 kW (20-30 HP) Terminal Designations
380-480V, 30-45 kW (40-60 HP) Terminal Designations
500-600V, 18.5-45 kW (25-60 HP) Terminal Designations
C
Frame
Required Branch
Circuit Disconnect
To Motor
1
1
1
1
1 User supplied.
