3-8 Mounting and Wiring Information Specific to Frames A1, A2, A3, and A4
Heat Sink Through-the-Back Mounting - Frames A1 through A3
98.0
(3.86)
196.0
(7.72)
210.0
1
(8.25)
182.1
(7.17)
220.0
(8.66)
234.2
(9.2204)
249.7
1
(9.83)
78.1
(3.076)
78.2
(3.080)
Cutout
10 Required
4.3 (0.171) Dia. for 10-32 x 12.7 (0.5) Self-Tap – 4.0 (0.159) for 10-32 x 12.7 (0.5) Threaded
Back of Enclosure
Drive
A1 = 50.8 (2.00)
A2 = 71.4 (2.81)
A3 = 98.8 (3.85)
All Dimensions in Millimeters and (Inches)
1
Shading indicates approximate size
of drive inside enclosure.
