3-4 Mounting and Wiring Information Specific to Frames A1, A2, A3, and A4
The terminal blocks provide the following:
Input Fusing Requirements The following are the input fusing requirements for frames A1 – A4.
This Terminal
Block:
Provides these Terminal
Numbers:
Which Provide Access to this Signal:
TB4
4, 7, 10 Shield ground
1, 2, 3 DC power supply
±10V DC
50 mA per voltage
5, 6, 8, 9 0 to ±10V DC output
Output impedance = 100 Ohms;
10mA maximum
11, 12 4 – 20 mA DC output Output impedance = 20 Ohms
TB7
3, 6, 9, 12 Shield Ground
1, 2, 4, 5 0 to ±10V DC input Input impedance = 20K Ohms
7, 8 4 – 20 mA input Input impedance = 130 Ohms
10, 11
Pulse input for frequency reference
+5V DC — Jumper J8 Set to 1 – 2
+12V DC — Jumper J8 Set to 2 – 3
Scale Factor (Pulse PPR) must be set
10mA minimum
TB10
12 Logic Earth Ground, Shield
1, 2, 3,
4, 5, 6,
7, 8, 9
Programmable contacts
Resistive rating = 115VAC/30VDC, 5.0A
Inductive rating = 115VAC/30VDC, 2.0A
10, 11
Voltage clearance. Provides physical space between the logic earth ground and other
signals on the terminal block.
Maximum Recommended AC Input Line Fuse Ratings (Fuses are User Supplied)
European Installations
North American
Installations
Drive Catalog
Number
kW (HP)
Rating
200 – 240V
Rating
380 – 480V
Rating
500 – 600V
Rating
The recommended fuse is Class
gG general industrial
applications and motor circuit
protection.
BS88 (British Standard) Parts 1
& 2*, EN60269-1, Parts 1 & 2,
type gG or equivalent should be
used for these drives. Fuses that
meet BS88 Parts 1 & 2 are
acceptable.
* Typical designations include,
but may not be limited to the
following:
Parts 1 & 2: AC, AD, BC, BD, CD,
DD, ED, EFS, EF, FF, FG, GF,
GG, GH
UL requirements specify
that UL Class CC, T, or
J
1
fuses must be used
for all drives in this
section*.
* Typical designations
include:
Type CC: KTK,
FNQ-R
Type J: JKS, LPJ
Type T: JJS, JJN
1336E-_ _ F05, 07
0.37 – 0.56
(0.5 – 0.75)
6A 3A —
1336E-_ _ F10 0.75 (1) 10A 6A 3A
1336E-_ _ F15 1.2 (1.5) 15A 6A —
1336E-_ _ F20 1.5 (2) 15A 10A 6A
1336E-_ _ F30 2.2 (3) 25A 15A 10A
1336E-_ _ F50 3.7 (5) 40A 20A 10A
1336E-_ _ F75 5.5 (7.5) — 20A 15A
1336E-_ _ F100 7.5 (10) — 30A 20A
1 Both fast acting and slow blow are acceptable.
