Mounting and Wiring Information Specific to Frames A1, A2, A3, and A4 3-3
Hard Wiring Your I/O You can use terminal blocks TB4, TB7, and TB10 for hardwiring
your I/O. These terminal blocks are shown in Figure 3.3.
Figure 3.3
Reference Signal Connections
J10 (TB10)
+
-
Analog Input 2
Shield
4 to 20 mA
Pulse Source
Shield
Shield
Shield
+
-
+
-
+
-
Analog Input 1
J7 (TB7)
1
2
3
6
9
12
4
5
7
8
10
11
Analog Output 2*
Shield
4 to 20 mA*
Shield
Shield
DC Power
Supply*
Analog Output 1*
+
-
+
-
+
-
+10V
Com
-10V
J4 (TB4)
1
2
3
6
9
12
4
5
7
8
10
11
123456789101112
Relay 1
Default: At Speed
Supply
Relay 2
Default: Enable
(Run)
Relay 3
Default: Not Fault
Relay 4
Default: Not Warning
(Alarm)
Voltage
Clearance
TE
* The power supply is for drive
input use only.
*NOTE: Analog I/O is differential, non-isolated I/O.
A (-) negative does not indicate common.
