Chapter 3
Mounting and Wiring Information
Specific to Frames A1, A2, A3, and
A4
Chapter Objectives Chapter 3 provides the mounting and wiring information specific to
frames A1, A2, A3, and A4.
Important: If your 1336 IMPACT drive is not an A1 – A4 frame
size, skip this chapter and read the mounting and wiring instructions
specific to your frame size. If you do not know what your frame size
is, refer to Chapter 1, Overview.
Wiring the Power The input and output connections for frames A1 – A4 are shown in
Figure 3.1.
Figure 3.1
Terminal Block Locations
This Topic: Starts on Page:
Wiring the power 3-1
Hard wiring your I/O 3-3
Input fusing requirements 3-4
Dimensions 3-5
TB3
TB4
TB10
Power Terminal Block
Control & Signal Wiring
Control Interface Option
TB1
TB4, 7, 10
TB3
TB1
Control Interface
Option
TB7
