E-2 CE Conformity
Filter Filter Selection
EMC Enclosure Kit Selection
RFI Filter Installation
Important: Refer to the instructions supplied with the filter for
details.
The RFI filter must be connected between the incoming AC supply
line and the drive input terminals.
Filter Catalog
Number
Three-Phase
Volts
Used with…
Frame
Reference
1336-RFB-7-A
200 – 240V 1336E-AQF05 – AQF10 A1
380 – 480V 1336E-BRF05 – BRF20 A1 – A2
1336-RFB-16-A
200 – 240V 1336E-AQF15 – AQF20 A2
380 – 480V 1336E-BRF30 – BRF50 A2 – A3
1336-RFB-30-A
200 – 240V 1336E-AQF30 – AQF50 A3
380 – 480V 1336E-BRF75 – BRF100 A4
1336-RFB-27-B
200 – 240V 1336E-A007 B
380 – 480V 1336E-B007 – B015 B
1336-RFB-48-B
200 – 240V 1336E-A010 – A015 B
380 – 480V 1336E-B020 – B030 B
1336-RFB-80-C
200 – 240V 1336E-A020 – A030 C
380 – 480V 1336E-BX040 – BX060 C
1336-RFB-150-D
200 – 240V 1336E-A040 – A050 D
380 – 480V 1336E-B060 – B100 D
1336-RFB-180-D
200 – 240V 1336E-A060 D
380 – 480V 1336E-B125 – BX150 D
1336-RFB-340-E
200 – 240V 1336E-A075 – A125 E
380 – 480V 1336E-B150 – B250 E
1336-RFB-475-G 380 – 480V 1336E-BX250 – B350 G
1336-RFB-590-G 380 – 480V 1336E-B400 – B450 G
1336-RFB-670-G 380 – 480V 1336E-B500 – B600 G
Not available 380 – 480V 1336E-B700 – B800 H
Frame
Reference
Enclosure Kit Catalog Number
200 – 240V Rating 380 – 480V Rating 500 – 600V Rating
A1, A2, A3 1336E-AE3 1336E-AE3 —
A4 1336E-AE2 1336E-AE2 1336E-AE2
B 1336E-AE4 1336E-AE4 1336E-AE4
C 1336E-AE5 1336E-AE5 1336E-AE5
D 1336E-AE6 1336E-AE6 1336E-AE6
E 1336E-AE7 1336E-AE7 1336E-AE7
F – H Not Available
