Appendix E
CE Conformity
EMC Directive This apparatus is tested to meet Council Directive 89/336
Electromagnetic Compatibility (EMC) using a technical construction
file and the following standards:
• EN 50081-1, -2 — Generic Emission Standard
• EN 50082-1, -2 — Generic Immunity Standard
Declarations of Conformity to the European Union Directives are
available. Please contact your Allen-Bradley Sales Representative.
Important: The conformity of the drive and filter to any standard
does not guarantee that the entire installation will conform. Many
other factors can influence the total installation and only direct
measurements can verify total conformity.
Requirements for Conforming
Installation
The following six items are required for CE conformance:
1. Standard 1336 IMPACT Drive 0.37 – 485 kW (0.5 – 650 HP) CE
compatible.
2. Factory installed EMC enclosure (-AE option) or field installed
EMC Enclosure Kit (1336x-AEx — see page E-2).
3. Filter as called out on the following page.
4. Grounding as shown on page E-3.
5. Input power (source to filter) and output power (filter to drive and
drive to motor) wiring must be braided, shielded cable with a
coverage of 75% or better, metal conduit or other with equivalent
or better attenuation, mounted with appropriate connectors. For
shielded cable it is recommended to use a compact strain relief
connector with double saddle clamp for filter and drive input and
compact strain relief connector with EMI protection for motor
output.
6. Control (I/O) and signal wiring must be in conduit or have
shielding with equivalent attenuation.
Marked for all applicable directives
1
1 Note: Installation guidelines stated below must be adhered to.
Emissions
Immunity
EN 50081-1
EN 50081-2
EN 55011 Class A
EN 55011 Class B
EN 50082-1
EN 50082-2
IEC 801-1, 2, 3, 4, 6, 8 per EN50082-1, 2
