Appendix D
Derating Guidelines
Chapter Objectives A number of factors can affect drive ratings. Appendix D contains the
derating guidelines for the 1336 IMPACT drive. If your drive is
affected by more than one factor, contact Rockwell Automation.
This catalog number: Is shown in:
1336E-AQF05 – 50 Figure D.1
1336E-A010 Figure D.2
1336E-A015 Figure D.3
1336E-A020 Figure D.4
1336E-A025 Figure D.5
1336E-A040 Figure D.6
1336E-A050 Figure D.7
1336E-A060 Figure D.8
1336E-A075 Figure D.9
1336E-A100 Figure D.10
1336E-BRF05 – 100 Figure D.1
1336E-B015 Figure D.11
1336E-B020 Figure D.2
1336E-B025 Figure D.12
1336E-B030 Figure D.3
1336E-B040 Figure D.4
1336E-BX040 Figure D.13
1336E-B050 Figure D.5
1336E-BX060 Figure D.5
1336E-B075 Figure D.14
1336E-B100 Figure D.15
1336E-B125 Figure D.16
1336E-B150 Figure D.9
1336E-BX150 Figure D.16
1336E-B200 Figure D.10
1336E-B250 Figure D.17
1336E-BP300 Figure D.18
1336E-BP350 FIgure D.19
1336E-BP400 Figure D.20
1336E-BP450 Figure D.21
1336E-B500 Figure D.22
1336E-B600 Figure D.23
1336E-B700C Figure D.24
1336E-B800C Figure D.24
1336E-C075 Figure D.25
1336E-C100 Figure D.26
1336E-C125 Figure D.27
1336E-C150 Figure D.28
1336E-C200 Figure D.29
1336E-C250 Figure D.30
1336E-CP350 Figure D.38
1336E-C400 Figure D.31
1336E-CP400 Figure D.39
1336E-C450 Figure D.32
1336E-C500 Figure D.37
1336E-C600 Figure D.38
1336E-C650 Figure D.39
1336E-C700C Figure D.39
1336E-C800C Figure D.39
