Using the Human Interface Module (HIM) C-13
To determine what version of the HIM you have, turn your module
over (remove it from the drive first, if necessary). The version is
located on the back of the HIM.
Removing the HIM For handheld operation, you can remove the module and place it up to
10 meters (33 feet) from the 1336 IMPACT drive.
Important: Removing a HIM (or other SCANport device) from a
drive while power is applied causes a Serial Fault, unless SP Enable
Mask (parameter 124) or Fault Select 1 (parameter 20) have been set
to disable this fault or Control Logic (from the Control Status menu)
has been disabled (only available on a Series A, version 3.0 or
Series B HIM). Setting bit 1 of SP Enable Mask to 0 disables Serial
Fault from a HIM on port 1. It also disables all HIM control functions
except Stop. Setting bit 9 of Fault Select 1 to 0 disables the serial fault
from the HIM on port 1 but still allows HIM control.
Version 3.00 Series A
• Version 1.04 and 1.01 Series B enhancements.
• The ability to display enums.
• The ability to change any digit of parameter values.
• The first fault displayed anywhere in the menu structure.
• The ability to change any digit of a password value by
using the Select key.
• The choice of process variables if more than one process
is available.
• The ability to clear all links.
• Additional parameter text for links.
• The Search menu structure.
• The Control Status menu structure.
• The ability to enable/disable the logic mask.
• The menu for the fault queue.
• The menu for the warning queue.
• The file/group structure.
If your HIM is older
than:
Then your HIM does not support:
!
ATTENTION: Some voltages present behind the drive
front cover are at incoming line potential. To avoid an
electric shock hazard, use extreme caution when
removing/replacing the HIM.
!
ATTENTION: Hazard of personal injury or equipment
damage exist. If you initiate a command to start motor
rotation (command a start or jog) and then disconnect
the programming device, the drive will not fault if you
have the SCANport communications fault set to be
ignored for that port.
