Using the Human Interface Module (HIM) C-7
Using the EEProm Mode
You can use EEProm mode to save values, recall values, reset values
to the factory defaults, upload a parameter profile from the drive to
the HIM, or download a parameter profile. To perform any of these
functions, you need to first enter EEProm mode by selecting it from
the Choose Mode prompt.
Saving Values/Recalling Values
The 1336 IMPACT drive automatically saves the values of the
parameters when you make a change. Therefore, you should not need
to use these functions in most situations. However, you can use these
functions to try to fix problems with the checksum value.
If you have a problem with the checksum, you can:
1. Select Recall Values.
2. Select Save Values.
3. Check the values of the parameters.
Resetting the Default Values
To reset the values of all parameters to the factory default values:
1. From the EEProm mode prompt, press INC or DEC until Reset
Defaults is displayed.
2. Press ENTER to restore all parameters to their original factory
setting.
3. Press Escape. Reprogram Fault is displayed.
4. Press the Stop key to reset the fault. If Input Mode was previously
set to a value other than 1, cycle drive power to reset.
Uploading a Parameter Profile
To upload a parameter profile from the drive to the HIM, you must
have a Series B HIM.
1. From the EEProm mode prompt, press INC or DEC until Drive –
> HIM is displayed.
2. Press ENTER. A profile name (up to 14 characters) is displayed
on line 2 of the HIM.
3. Change this name or enter a new name. Use SEL to move the
cursor to the left. Use INC or DEC to change the characters.
4. Press ENTER. An informational display is shown. This display
indicates the drive type and firmware version.
5. Press ENTER to start the upload. The parameter number
currently being uploaded is displayed on line 1 of the HIM.
Line 2 indicates the total progress. Press ESC to stop the upload.
6. Press ENTER when COMPLETE is displayed on line 2. If line 2
reports ERROR, refer to the Troubleshooting section.
