C-4 Using the Human Interface Module (HIM)
Figure C.3
HIM Menu Tree
Power-Up and
Status Display
Choose Mode
or or or or
EEProm Search Password Display Process
Program
Link Start Up
Operator Level
Mode Level
Parameters
Links
Save Values
Recall Values
Reset Defaults
Drive to HIM
HIM to Drive
Control Logic
Reset Drive
1
Fault Queue
Warning Queue
Login
Logout
Modify
Set Links
Clear All Links
File Level
Parameter Files
Group Level
Parameter Groups
Element Level
Parameters
Control
Status
Process Display
1
Not available before Version 1.06 Series B.
