Appendix C
Using the Human Interface Module
(HIM)
Chapter Objectives Appendix C provides information so that you can use your Human
Interface Module (HIM) more effectively.
What Is the Human Interface
Module (HIM)?
The Human Interface Module (HIM) is the standard user interface for
the 1336 IMPACT drive. When the drive mounted HIM is supplied,
you can access it from the front of the drive. The HIM provides a way
to program the drive and to view the operating parameters. The HIM
also lets you control different drive functions.
The HIM contains a display panel and a control panel. The display
panel lets you program the drive and view the various operating
parameters. The control panel lets you control different drive
functions.
This topic: Starts on page:
What is the Human Interface Module (HIM) C-1
How does the HIM work C-3
HIM compatibility information C-12
Removing the HIM C-13
!
ATTENTION: When a drive mounted HIM is not
supplied on enclosed NEMA Type 1 (IP20) drives, you
must install the blank cover plate (option HAB) to close
the opening in the front cover of the enclosure. Failure to
install the blank cover plate allows access to electrically
live parts that may result in personal injury and/or
equipment damage.
When a drive mounted HIM is supplied with enclosed
NEMA Type 1 (IP 20) drives, but has been removed
from its mounting cradle for remote operation, you must
install the blank cover plate in place of the HIM.
