B-34 Control Block Diagrams
The following is the inverter overload curve for the 460V/800 HP
frame H.
100%
110%
120%
130%
140%
150%
160%
170%
180%
190%
200%
10 100 1000 10000
Seconds to Trip
Percent Rated Inverter Current
Inverter Overload
Inverter Overload Pending
60 second Overload @ 150%
30 second Pending @ 150%
105%
Inverter Overload Curves
30 second Pending @ 135%
60 second Ov er
load @ 135%
105%
200%
150%
160%
170%
180%
190%
110%
120%
130%
140%
100%
10010 1000 10000
Seconds to Trip
Percent Rated Inverter Current
Overload Foldback
Overload Warning
135%
Inverter Overload Curves (H Frame)
