Bit 0 — Normal Stop
Bit 1 — Start
Bit 2 — Jog 1
Bit 3 — Clear Fault
Bit 4 — Forward
Bit 5 — Reverse
Bit 6 — Jog 2
Bit 7 — Current Limit Stop
Bit 8 — Coast–to–Stop
Bit 9 — Speed Ramp Disable
Bit 10 — Flux Enable – Magnetizing Flux
Bit 11 — Process Trim Enable
Bit 12 — Speed Ref A
Bit 13 — Speed Ref B
Bit 14 — Speed Ref C
Bit 15 — Reset Drive
C B A
0 0 0 — No Change
0 0 1 — Speed Ref 1
0 1 0 — Speed Ref 2
0 1 1 — Speed Ref 3
1 0 0 — Speed Ref 4
1 0 1 — Speed Ref 5
1 1 0 — Speed Ref 6
1 1 1 — Speed Ref 7
Dir/Ref Owner (Par 128)
Start/Stop Owner (Par 129)
Jog1/Jog2 Owner (Par 130)
Ramp/ClFlt Owner (Par 131)
Flux/Trim Owner (Par 132)
Logic Input Sts (Par 14)
SP Enable Mask (Par 124)
Start/Jog Mask (Par 126)
Clr Flt/Res Mask (Par 127)
Dir/Ref Mask (Par 125)
Dir/Ref Mask (Par 125)
Clr Flt/Res Mask (Par 127)
SCANport 1
SCANport 2
SCANport 3
SCANport 4
SCANport 5
SCANport 6
(Gateway)
L Option Board
Logic Cmd Input
(parameter 197)
Bit 0 — Run Ready Bit 8 — At Set Speed
Bit 1 — Running Bit 9 — Enable LED
Bit 2 — Command Dir Bit 10 — Stopped
Bit 3 — Rotating Dir Bit 11 — Stopping
Bit 4 — Accelerating Bit 12 — At Zero Spd
Bit 5 — Decelerating Bit 13 — Speed Ref A
Bit 6 — Warning Bit 14 — Speed Ref B
Bit 7 — Faulted Bit 15 — Speed Ref C
C B A
0 0 0 — No Change
0 0 1 — Speed Ref 1
0 1 0 — Speed Ref 2
0 1 1 — Speed Ref 3
1 0 0 — Speed Ref 4
1 0 1 — Speed Ref 5
1 1 0 — Speed Ref 6
1 1 1 — Speed Ref 7
Drive/Inv Status (Par 15)
