A-4 Specifications
Input/Output Ratings The input and output current ratings grouped by drive voltage rating
are provided in the following tables:
200 – 240V 380 – 480V 500 - 600V
Cat No. Input kVA
Input
Amps
Output
kVA
Output
Amps
Cat No. Input kVA
Input
Amps
Output
kVA
Output
Amps
Cat No.
Input
kVA
Input
Amps
Output
kVA
Output
Amps
AQF05 1.48 2.8 0.92 2.3
BRF05 1.54 1.4 0.96 1.2 CWF10 3.56 3 2.49 2.5
AQF07 1.93 3.5 1.20 3.0 BRF07 2.18 2.1 1.35 1.7 CWF20 5.98 4 4.18 4.2
AQF10 2.89 5.4 1.79 4.5 BRF10 2.96 2.8 1.83 2.3 CWF30 8.54 6 5.98 6.0
AQF15 3.86 7.3 2.39 6.0 BRF15 3.86 3.5 2.39 3.0 CWF50 11.24 8 7.87 7.9
AQF20 5.14 9.7 3.19 8.0 BRF20 5.14 4.8 3.19 4.0 CWF75 9 – 11 10 10 9.9
AQF30 7.71 14.3 4.78 12.0 BRF30 7.71 7.2 4.78 6.0 CWF100 11 – 13 12 12 12.0
AQF50 11.57 21.3 7.17 18.0 BRF50 11.57 12.0 7.17 10.4 C015 17 – 20 19 19 18.9
A007 10 – 12 28 11 27.2 BRF75 19.92 14 13.94 13.9 C020 21 – 26 25 24 23.6
A010 12 – 14 35 14 33.7 BRF100 28.46 25 19.92 24.0 C025 27 – 32 31 30 30.0
A015 17 – 20 49 19 48.2 B015 18 – 23 28 22 27.2 C030 31 – 37 36 35 34.6
A020 23 – 28 67 26 64.5 B020 23 – 29 35 27 33.7 C040 40 – 48 46 45 45.1
A025 25 – 30 73 31 78.2 B025 23 – 26 43 33 41.8 C050 48 – 57 55 57 57.2
A030 27 – 30 79 32 80.0 B030 32 – 41 49 38 48.2 C060 52 – 62 60 62 61.6
A040 43 – 51 123 48 120.3 BX040 40 – 50 62 47 58.7 C075 73 – 88 84 85 85.8
A050 53 – 64 154 60 149.2 B040 41 – 52 63 52 64.5 C100 94 – 112 108 109 109.1
A060 60 – 72 174 72 180.4 B050 48 – 60 75 61 78.2 C125 118 – 142 137 137 138.6
A075 82 – 99 238 96 240.0 BX060 62 75 61 78.2 C150 136 – 163 157 157 159.7
A100 100 – 120 289 116 291.4 B060 61 – 77 93 76 96.9 C200 217 – 261 251 251 252.6
A125 112 – 135 325 130 327.4 B075 78 – 99 119 96 120.3 C250 244 – 293 282 283 283.6
B100 98 – 124 149 120 149.2 C300 256 – 307 296 297 298.0
B125 117 – 148 178 143 180.4 CX300 256 – 307 295 297 298.0
BX150 148 178 143 180.4 C350 304 – 364 351 352 353.6
B150 157 – 198 238 191 240.0 CP350 301 – 361 347 349 350.0
B200 191 – 241 290 233 291.4 CPR350 301 – 361 347 349 350.0
B250 212 – 268 322 259 327.4 C400 349 – 419 403 405 406.4
B/BP300 265 – 335 403 324 406.4 CP400 343 – 412 397 398 400.0
BPR300 265 – 334 402 324 406.4 CPR400 343 – 412 397 398 400.0
B/BP350 300 – 379 455 366 459.2 C450 394 – 473 455 457 459.2
BPR350 300 – 379 455 366 459.2 C500 434 – 520 501 503 505.1
B400 330 – 416 501 402 505.1 C600 514 – 617 594 597 599.2
BP400 313-396 476 383 481.0 C650 578 – 694 668 671 673.4
BPR400 313 – 396 476 383 481.0 C700C 616 – 739 756 767 770
B450 372 – 470 565 454 570.2 C800C 639 – 767 786 797 800
BP450 346 – 437 526 424 531.7 12C700C 616 – 739 756 767 770
BPR450 346 – 437 526 424 531.7 12C800C 639 – 767 786 797 800
B500 391 – 494 594 477 599.2
B600 439 – 555 668 537 673.4
BP300 265 – 334 402 324 406.4
BP350 300 – 378 455 366 459.2
BP400 313 – 396 476 383 481.0
BP450 346 – 437 526 424 531.7
B700C 517 – 625 835 677 850
B800C 647 – 817 965 783 983
12B700C 517 – 625 835 677 850
12B800C 647 – 817 965 783 983
