Appendix A
Specifications
Chapter Objectives Appendix A provides the specifications for the 1336 IMPACT drive.
Specifications The following table shows the specifications for the 1336 IMPACT
drive:
This topic: Starts on page:
Specifications A-1
Input/output ratings A-4
Cable and wiring requirements A-5
Software block diagrams A-6
This category: Has these specifications:
Environmental
Ambient operating temperature
IP00, Open: 0 to 50° C (32 to 122° F)
IP20, NEMA Type 1 Enclosed: 0 to 40° C (32 to 104° F)
IP65, NEMA Type 4 Enclosed: 0 to 40° C (32 to 104° F)
Storage temperature (all constructions) -40 to 70° C (-40 to 158° F)
Atmosphere
Important: Drive must not be installed in an area where the ambient atmosphere contains
volatile or corrosive gas, vapors or dust. If the drive is not going to be installed for a period of
time, it must be stored in an area where it will not be exposed to a corrosive atmosphere.
Relative humidity 5 to 95% non-condensing
Altitude 1000m (3300 ft) without derating
Shock 15g peak for 11 ms duration (+1.0 ms)
Vibration 0.152 mm (0.006 inches) displacement. 1g peak
