2-12 Mounting and Wiring Your 1336 IMPACT Drive
Use the information in the following table along with the enclosure
manufacturer’s guidelines for sizing.
Catalog Number Base Derate Amps
1
Derate Curve
2,3
Heat Dissipation
Drive Watts
2,3
Heatsink Watts
2
Total Watts
2
200 – 240V drives
AQF05 2.3 Figure D.1 13 15 28
AQF07 3.0 Figure D.1 15 21 36
AQF10 4.5 Figure D.1 17 32 49
AQF15 6.0 Figure D.1 21 42 63
AQF20 8.0 Figure D.1 25 56 81
AQF30 12.0 Figure D.1 33 72 105
AQF50 18.0 Figure D.1 42 116 158
A007 27.2 none 156 486 642
A010 33.7 Figure D.2 200 721 921
A015 48.2 Figure D.3 205 819 1024
A020 64.5 Figure D.4 210 933 1143
A025 78.2 Figure D.5 215 1110 1325
A030 80.0 None 220 1110 1330
A040 120.3 Figure D.6 361 1708 2069
A050 149.2 Figure D.7 426 1944 2370
A060 180.4 Figure D.8 522 2664 3186
A075 240.0 Figure D.9 606 2769 3375
A100 291.4 Figure D.10 755 3700 4455
A125 327.4 Same as B250 902 4100 5002
380 – 480V drives
BRF05 1.2 Figure D.1 12 9 21
BRF07 1.7 Figure D.1 13 15 28
BRF10 2.3 Figure D.1 15 20 35
BRF15 3.0 Figure D.1 16 27 43
BRF20 4.0 Figure D.1 19 36 55
BRF30 6.0 Figure D.1 23 54 77
BRF50 10.4 Figure D.1 29 84 113
BRF75 13.9 Figure D.1 70 230 300
BRF100 24.0 Figure D.1 89 331 420
B015 27.2 Figure D.11 117 486 603
B020 33.7 Figure D.2 140 628 768
B025 41.8 Figure D.12 141 720 861
B030 48.2 Figure D.3 141 820 961
BX040 58.7 Figure D.13 175 933 1108
B040 64.5 Figure D.4 175 933 1108
B050 78.2 Figure D.5 193 1110 1303
BX060 78.2 Figure D.5 193 1110 1303
B060 96.9
4
361 1708 2069
1 Base derate amps are based on nominal voltage (240, 480, or 600V). If the input voltage exceeds the drive rating, the drive output must be
derated. Refer to Figure D.41.
2 Drive ambient temperature rating is 40°C. If ambient exceeds 40°C, derate the drive. Refer to Figures D.1 – D.39.
3 Drive rating is based on altitudes of 1000m (3000ft) or less. If installed at a higher altitude, derate the drive. Refer to Figure D.40.
4 Not available at time of publication.
